17IWD Al/CCA wire Intermediate drawing machine
1,Main technique parameter:
1. Usage: Aluminum/CCAwire
2. Inlet diameter: 3.0-3.5mm
3. Outlet diameter: 2.5mm-0.6mm
4. Maximum drawing speed: 1200m/min
5. Dies number: 17 (Customer self provided) 30mm*8
6. Mechanism surface reduce rate:
From No.1 to No.16 18%
No.17 12.5%
7. Drawing method: 4 shafts horizontal arrangement; sliding continuous drawing
8. Drive motor: 37KW/AC frequency converter control
9. Spooler motor: 11KW/AC frequency converter control
10. Frame: Ironed cast
11. Transmission: All transmission by flat belts; main motor lubricated by petroleum
12. Capstan: four-tier capstan; tungsten carbide (6 months of guarantee)
13. Lubrication system: Spray type; lubrication oil 100 liter/min (without water pump)
14. Spooler: Without shaft;
Automatically pneumatic brake when wire is broken;
Single shaft fixed with screw (manually self-lock)
Manual hydraulic unloading (with loading & unloading cart)
15. Spool dimension: 500/630mm
| Outer diameter | Inner diameter | Outer wide | Inner wide | Bore diameter | Position bolt |
| 630 | 360 | 430 | 400 | 127 | 200 |
| 500 | 360 | 346 | 322 | 127 | 200 |
16. Capacity for wire receiving: 200-500KG
17. Traversing unit:
Traversing system: 90W low speed reversible motor type;
Traversing width: 480mm/Max
18. Spooling tension control: Pneumatic balance automatically controls spooling tension (pneumatic source provided by customer self)
More options
RBD-400/13 Capstan Type Aluminum rod Breakdown Machine
RBD-400/13 Aluminum rod breakdown machine is used to draw Φ9.5mm ordinary aluminum rod into Φ1.7mm-Φ4.5mm wire, Drawing capstans are arranged in a line. Fixed speed capstan and other twelve drawing capstans are controlled by two electric motors respectively. It is with quickly change dies system.
1. Main technical parameters:
1.1 Max inlet diameter: Φ9.5mm
1.2 Outlet diameter: Φ1.7mm-Φ4.5 mm
1.3 Max. drawing speed: 25m/s
1.4 Diameter of drawing capstan: Φ400
1.5 Max. No. of drawing dies: 13 dies
1.6 Size of drawing dies: Φ38×25
1.7 Max storage capacity of wire accumulator: 8m
1.8 Motor power of drawing machine : 200KW AC
1.9 Motor power of fixed speed capstan: 55KW (AC)
1.10 Motor power of dual-spool take-up: 15KW*2 (AC)
2. Components of machine:
2.1 Pay-off stand with a rotating arm: 1 Set
2.2 Host drawing machine: 1 Set
2.3 Dancer: 1 Set
2.4 Double spooler take up 1 set
2.5 wire pointer machine: 1 Set
2.6 Electric control system and console : 1 Set.
More options
![Aluminum Wire Drawing Machine Inlet 3.0 To 3.5mm Outlet 0.6 To 2.5mm CCA Wired Drawing Machine]()
Compact and cost-effective
13D/400-Aluminium rod breakdown machine
1. usage
This machine mainly used to drawing Φ9.5mm ordinary AL- rod into φ1.7-φ3.0mm wire.With quick change die system.
2.Quick change die system-drawing die sheet:
Inlet 9.5mm,outlet 1.7-3.0mm
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 |
| 8.33 | 7.30 | 6.40 | 5.61 | 4.90 | 4.30 | 3.77 | 3.30 | 2.90 | 2.54 | 2.23 | 1.95 | 1.70 |
Quick change die system:For example, if you want to produce 2mm, you only remove 1.95 and 1.7, and put the 2mm at final drawing die seat;If you want to produce 3mm, you remove 2.90-2.54-2.23-1.95-1.70mm, put 3mm at final drawing die seat.)
| Model | 11/400 | 13/400 | 15/350 |
| Inlet Dia.-mm | 9.5 | 9.5 | 9.5 |
| Outlet Dia.-mm | 5.0-2.15 | 3.5-1.68 | 2.3-1.5 |
| Draw No. | 11 | 13 | 15 |
| Last Pulley Dia.mm | 400 | 400 | 350 |
| Max speed m/s | 12 | 15 | 15 |
Speed increasing
ratio for last die | adjustable | adjustable | adjustable |
| Motor Power-KW | 90KW+15KW | 75KW+11KW | 75KW+7.5KW |
| Take up | Single spool Takeup
Dual spool Takeup | Single spool Takeup
Dual spool Takeup | Single spool Takeup
Dual spool Takeup |
| Features | Speed increasing ratio for last die be adjustable,
no need to change all die setting for different size of product
less die maintenance and cost-saving solution |
